Appliaction of GGBS Vertical Roller Mill supplier

vertical mill is one of the most important cement equipment. It is the key grinding machine of materials being crushed. The cement grinding mill plays a vital role in cement production line and cement production process. Cement mill is widely used in cement, silicate products, new building materials, refractory materials, fertilizer, ferrous and non-ferrous metals beneficiation, ceramics and other production industries. It makes dry or wet grinding for all kinds of ores and other grind-able materials.


Working Principle of GGBS Vertical Roller Mill supplier

In a vertical roller mill, materials to be ground fall upon the center of a rotating grinding table. Centrifugal force causes the materials to spread out evenly towards the edge of the plate. As particles lying flatly on the plate reach a certain thickness, they are ground or crushed by multiple pairs of rollers.

When the crushed particles fall off the edge of the grinding table, they are met by a strong flow of hot air that has just passed through the nozzle ring at the bottom, which brings them through the center of milling chamber and out the top before entering the separator. During this process, the flying particles absorb enough heat from the hot air, causing the moisture contained in particles to evaporate rapidly.

Once inside the separator, particles finer than the required size pass through the separation device while larger ones fall upon the grinding table once again for further grinding. The desired fully-ground particles enter the finished product warehouse.


Technical Parameters

ModelGrinding table diameterRoller diameterRoller numberMotorOutput
D (mm)D (mm)(n)P (kW)Q (t/h)
GRMS33.31320017003160050
GRMS35.41350018004180060
GRMS40.41400019004224070
GRMS43.41430021204280090
GRMS46.414600224043150105
GRMS48.414800224043550125
GRMS50.415000236043800140
GRMS53.415300250044200160
GRMS56.615600250065000180

Note: mill spectral pattern benchmark

(1) Material medium friction (MFs)=0.9~1.0;

(2) Material moisture max 15%;

(3) Refined powder granularity 4200~4500 cm²/g;

(4) Refined powder moisture 0.5~1.0%;

(5) The concrete mill installed power and technology parameter will be adjusted appropritely basing on the actual material property and requirements of owner;

Advantages of Our GGBS Vertical Roller Mill supplier

High-performance separator and optimised airflow ensure high separation efficiency and low pressure loss for energy saving.

Unusually large rollers permit coarse feed and ensure a thick grinding bed for maximum uptime.

All impact forces and dynamic reactions are small and vertical therefore easy to accommodate – prevents mill stops.

Segmented wear parts for table and rollers allow use of the most wear-resistant materials and hardfacing for long life.

Reversible roller segments ensure high material utilisation.

External circulation limits power consumption of fan.

Feed sluice ensures low false air flow and steady feed flow for minimum power consumption and optimum mill production.

The raw mill is easily adaptable to high airflow required by especially wet easy to grind materials.
